High Quality Wholesale Customized Nickel Plated Copper Wire

Short Description:

Nickel plated copper wire is divided into nickel plated soft round copper wire and nickel plated hard round copper wire. Nickel plated soft round copper wire is annealed to be changed its physical properties in order to get soft. Good nickel plated copper wire’s coating is continuously and firmly attached to the surface of the conductor and the surface would not be stained after tests. The coating surface of nickel plated copper wire should be smooth and continuous, free from harmful defects such as nickel particles, burrs and mechanical damage.




  • Standard: GB11019 or ASTM B355-95
  • HS Code: 7408190090
  • Place of Origin: Shanghai, China
  • Certification: ROHS
  • Product Detail

    Product Tags

    nickel

    Shanghai Tianchuang Cable Technology Development Co., Ltd. was founded in 2007, the company specializing in the production of metallic conductor.Our company has been concentrating on the brand management and the development of the innovation of product technology. Our company has obtained the ISO9001 quality management system certification.Now we provide various kinds of special wire material for the industries in terms of internal aviation and spaceflight,electron information and military industry and some branch production,etc.We played a very important role in our national important projects,the establishment of national defense and international engineering.

    NICKEL-PLATED COPPER  WIRE
    Name Nickel-plated copper wire
    Model TRN
    Diameter(mm) 0.08-1.13
    Materials and product standards
    Copper wire GB/T3953
    Nickel-plated copper wire GB11019-2009
    Dimensions and Deviations
    Diameter standard (mm) Deviation
    0.110-0.250 ±0.005
    0.251-0.700 ±0.010
    0.710-1.000 ±0.015
    1.100-1.130 ±0.020

    Product Details

    Plated Copper Wire
    2
    15 Awg Nickel Plated Copper Wire
    Nickel Plated Copper Wire

    Product Processes

    Nickel plated copper wire is divided into nickel plated soft round copper wire and nickel plated hard round copper wire. Nickel plated soft round copper wire is annealed to be changed its physical properties in order to get soft. Good nickel plated copper wire’s coating is continuously and firmly attached to the surface of the conductor and the surface would not be stained after tests. The coating surface of nickel plated copper wire should be smooth and continuous, free from harmful defects such as nickel particles, burrs and mechanical damage.

    Plated Copper Wire

    Packing and delivery

    1.The mono-filament and its winch are supplied in plates, and then packed and delivered in boxes after proper packaging with Kraft paper and packaging film. The small size disc is fixed by custom foam, and the large size plastic rubber disk or iron disk is fixed by custom wooden frame.

    2.The mono-filament and its strand are evenly wound on the wire shaft, the wire arrangement is not pressed, the wire head is fixed, and the outermost side of the wire is kept at a certain distance from the edge of the disk, so as to avoid collision in the course of transportation.

    The Application Field of Products

    application1 (1)

    Application: Non-ferrous wire, textile thread, high frequency application, micro cable, aerospace cable, high temperature cable, etc.

    Features: High electrical conductivity, high heat resistance, bright and shiny surface, high frequency characteristics, high temperature resistance, corrosion resistance, etc.

    Exhibition and Certification

    The Application Field of Products
    certificate

    FAQ

    Q1: What are your prices?
    A1: Our prices are subject to change depending on supply and other market factors.

    Q2: What is the product warranty?

    A2: We warranty our materials and workmanship. Our commitment is to your satisfaction with our products.

    Q3: What kinds of payment methods do you accept?
    A3: You can make the payment to our bank account, Western Union or PayPal: 30% deposit in advance, 70% balance against the copy of B/L.

    Q4: What is the average lead time?
    A4: For samples, the lead time is about 7 days. For mass production, the lead time is 20-30 days after receiving the deposit payment.
