good oxidative source factory resistance silver plated copper wire for factory

Short Description:

Silver plated copper wire is a kind of thin wires which is silver-plated low-oxygen or oxygen free copper wire stretched by wire drawing machines.Features: High electrical conductivity, high heat resistance, bright and shiny surface, high frequency characteristics, high temperature resistance, corrosion resistance, etc.

  • Place of Origin: Shanghai, China
  • Brand Name: Shanghai Tianchuang
  • Certification: ISO9001/ROHS/REACH
  • HS Code: 7408190090
  • MOQ: 50 Kilograms
  • Payments: This supplier also supports L/C,D/A,D/P,T/T payments.
  • Product Detail

    Product Tags

    Silver plated copper wire is divided into silver-plated soft round copper wire and silver-plated hard round copper wire. Silver plated soft round copper wire is annealed to be changed its physical properties in order to get soft. Good silver-plated copper wire’s coating is continuously and firmly attached to the surface of the conductor and the surface would not be stained after tests. The coating surface of silver plated copper wire should be smooth and continuous, free from harmful defects such as silver particles, burrs and mechanical damage.

    Medel TRY
    Diameter(mm) 0.02-3.83
    Product standards JB/T3135 or ASTM B298-99
    Resisitivity  Not more than 0.017241 Ω.mm²/m, at 20℃, resistance temperaturecoefficient 0.0391/℃


    Plated Copper Wire

    The silver plated copper wire combines the characteristics of copper and silver- excellent electrical conductivity, bright and shiny surface. What’s more, The silver plating layer has high corrosion resistance. Because of these advantages, silver-plated copper wire becomes processed product for people to make high frequency wire and colored textile wire.

    Plated Copper Wire



    Application: Non-ferrous wire, textile thread, high frequency application, micro cable, aerospace cable, high temperature cable, etc.

      various fields


    Inspection rules
    Product inspection: incoming material inspection-process inspection-finished product inspection, finished product inspection qualified factory, each batch of products is accompanied by quality inspection certificate.
